| 【 Main technical parameters 】 |
| Product Name | Dongfeng 6x4 Dust Suppression Truck |
| Wheelbase | 4350+1350（mm） |
| Engine Model | Cummins D6.7NS6B230 230HP
Yuchai YCS06245-60 245HP |
| Displacement | 6700（ML）/169（KW）
6234（ML）/180（KW） |
| Tank Volume | 16CBM |
| Watering Width | ≥14M Height≥28M |
| Quiet Wind Maximum Range | ≥100（米） |
| Power Of Generator Set | Diesel 150（KW） |
| Fan Motor Power | 45 (KW) Equipped With Aluminum Alloy Fan Blades |
| Power Of Driving Water Pump | 11 (KW) Stainless Steel Multi-Stage Centrifugal Pump |
The main structure of the multifunctional dust suppression truck is modified by adding a square shaped large capacity water tank, an efficient remote fog gun system, a high-power dedicated self suction and self drainage pump, a medium and low pressure flushing and sprinkler system, and a green sprinkler anti-aircraft gun (automatic sprinkler anti-aircraft gun can be optionally installed at the front end of the tank) on the walking mechanism. Tank volume (square and round tank volume of 16 cubic meters), exempt from product tax.
Advantages
1. Strong capacity, long range, strong penetration, strong adhesion of fog particles, wide coverage, and precision spray.
2. High working efficiency and fast spray speed; When spraying water for dust removal in storage yards that are prone to causing dust, the sprayed mist particles are small and come into contact with the floating dust, forming a moist mist shape that can quickly suppress dust settling. The settling rate of mist can reach over 80-90%.
3. The secondary atomization technology adopts a specific starting turbine wind aid device to change the wind direction to form an angle with the flow direction of the mist particles, promoting sufficient water atomization.
4. When the droplets are ejected from the nozzle, they are further broken by the high-speed high-pressure air flow in the spray area, which gradually increases the speed of the droplets and improves the degree of atomization. The atomization can generally reach about 50-150 um diameter droplets. The supporting power is flexible, which can be powered by both three-phase 380V mains power and generator sets.
5. The supporting generator set is installed on the transportation vehicle for power supply, with flexible operation, safe and reliable use, and manual control operation.
6. Compared to other dust suppression spraying equipment, water consumption can be saved by 70% to 80% (spray guns, sprinklers), and the area covered by water mist is much larger than that of other dust suppression spraying equipment.
