Dongfeng KR Road Washing Sweeper Truck
| NAME | SPECIFICATIONS |
| 1 | Vehicle Model | RLQ5180TXSD6 |
| 2 | Chassis Model | DFH1180EX8 |
| 3 | Tank Volume | 16CBM |
| 4 | Wheelbase | 5000MM |
| 5 | Engine Horsepower | 230HP |
| 6 | Total Weight | 18000KG |
| 7 | Rated Load Capacity | 6405KG |
| 8 | Curb Weight | 11750KG |
| 9 | Vehicle Dimensions | 8620*2500*3120MM |
Chassis Configuration:
Equipped with Dongfeng Tianjin Guoliu Kangji 230 horsepower engine and wheelbase 5000mm, Fast eight speed, 10.00 steel wire tire, electric glass central locking, with air conditioning.
Upper Body Configuration:
9 cubic electrophoresis process carbon steel water tank/7 cubic stainless steel garbage bin, electrophoresis sub frame, 2 center mounted scanning disks, suction cups of the same model as Zhonglian (Jiermei), Kangji 170 horsepower auxiliary engine, 8.0 maintenance free centrifugal fan, powerful motor, Yifeng 60-90 low-pressure water pump (front flushing), central flushing sprinkler function. JPE high-pressure water pump (front spray, side spray, middle spray, rear spray/washing water gun/dustbin self-cleaning device), universal high-pressure roadside cleaning nozzle, touch screen control panel, safety brace with sensor, rear LED arrow light, water tank with anti overflow/low water level alarm device. Emergency manual pump, Hepres solenoid valve group, reverse/work monitor, 15 meter high-pressure flushing reel. Maximum cleaning width of 3.5 meters.
