| 【 Main technical parameters 】 |
|
| [Technical Parameters of the Entire Vehicle] |
| Kerb Weight (Kg) | 18000 |
| Garbage Tank Volume (m3) | 7 |
| Tank Material | Stainless Steel / CARBON STEEL |
| Max.Cleaning Width(m) | 3.5 |
| Tipper unloading angle(°) | 45 |
| Secondary engine Power(HP) | 170 |
| Overall Dimensions (mm) | 8620×2500×3120 |
| Water Tank Volume (m3) | 9 |
| Sweeper brush | 2 |
| Speed of Road Cleaning(km/h) | 15-20 |
| Max.Sweeping Capacity(m2/h) | 54000 |
| Max. Suction size(mm) | 100 |
| Sweeping Efficiency (%) | 95 |
| [Chassis Technical Parameters] |
| Brand Name | DONGFENG |
| Fuel Type | diesel |
| Front Axle/Rear Axle (t) | 4/8 |
| Number of Axles | 2 |
| Number of Tires | 6 |
| Brake | Air Brake/Oil Brake |
| Engine Power(HP) | 230 |
| Gearbox Model | 8-Speed Manual |
| Wheelbase (mm) | 5000 |
| Tire Size | 10R20 18PR |
2 central sweep trays, Zhonglian (Germe) suction cups, Yifeng 60-90 low pressure Pump (front flush), central hedge sprinkler function. JPE high pressure pump (front spray, side spray,middle spray, post spray/rinse water gun/bin self-cleaning device), universal high pressure roadside cleaning Nozzle, touch screen control panel, safety lever with sensor, tail LED arrow light,Water tank with anti overflow/low water alarm device. Emergency hand pump, Hypres solenoid valve set,Astern/work monitor.
