XBZ5250ZSLL61
KANGMU
Dongfeng LZM Bulk Feed Trailer
NAME | SPECIFICATIONS | |
1 | Vehicle'Shortest Length | 9180MM |
2 | Vehicle Model | XBZ5250ZSLL61 |
3 | Tank Dimension | 6300、6800×2550×2500Mm |
4 | Unloading Speed | 500-600Kg/Min |
5 | Rotation Angle Of Auger Conveyor | ±180° |
6 | Maximum Distance For Horizontal Conveying | 7.8M(Optional) |
7 | Maximum Elevation Angle Of Auger Conveyor | 60° |
8 | Tank Volume | 32CBM |
9 | Maximum Distance For Vertical Conveying | 8.5M |
10 | Auger Conveyor Diameter | 273MM |
11 | Loading Tonnage | 16-18 Tons |
12 | Unloading Time | 35Min |
13 | Residual Rate | 0.01% |
14 | Tank Compartments | 3(Optional) |
Vehicle Configuration:
Unloading principle: Hydraulic winch, blade rotating winch, blade material alloy steel;
Unloading system (blade rotation) horizontal winch (273mm for feeding at the bottom of the horizontal tank), vertical winch (273mm for lifting), movable winch (219mm for discharging at the top)
Operating System: The electric operating system adopts three 5.5KW imported Siemens three-phase asynchronous motors, electrical control system, equipped with a 30 meter external power cord, with remote control, advantages of low vibration and noise. Waterproof and dustproof, etc.
Hydraulic operating system: imported accessories: Denison hydraulic pump, Eaton hydraulic motor, hydraulic valve: Taiwan Oil Power, with radiator, with remote control.
Chassis Configuration:
Yuchai 290 horsepower engine, H5 high top two bedroom cab, Fasttech 9JS119TA gearbox, 5.5-ton front axle, 400 rear axle, wheelbase 2050+3550450L aluminum alloy fuel tank, 295 vacuum tires, 280 reinforced single-layer beam, front mechanical rear airbag cab suspension, electric hydraulic flip, laminated glass, electric glass lifter, airbag shock absorber driver's seat, metallic paint, electromagnetic clutch fan, brand new interior, LCD instrument panel, MP3+radio, automatic air conditioning, cruise control system ABS、 In car terminal (driving recorder+compatible with Beidou GPS), external sunshade, aluminum alloy air tank, central locking system, automatic adjustment arm, polymorphic switch, leather multifunctional steering wheel, right turn prompt sound.
