High-End 55cbm 2 Axles Carbon Steel And Aluminium Alloy Feed Trailer

Name: High-End 55cbm 2 Axles Carbon Steel And Aluminium Alloy Feed Trailer
Brand: KANGMU
Rating: 5.0 (26 reviews)

Product Specifications:

Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd.
Product Name: High-End 55cbm 2 Axles Carbon Steel and Aluminium Alloy Feed Trailer
Keywords: Bulk Feed Truck
Attributes: With After-Sale Service, One Year Warranty, Truck

Availability:

Quantity:



Inquire Add to Basket

Brand:
KANGMU

Features

High-End 55cbm 2 Axles Carbon Steel and Aluminium Alloy Feed Trailer

Category	Specifications
Vehicle Dimensions	10500mm * 2550mm * 3950mm
Total Volume	55 m³
Curb Weight	9390 kg
Compartment Configuration	Divided into 8 compartments, each layer controlled by an independent compartment lever
Body Material (Front/Rear/Bottom/Side Panels/Partitions)	High-quality 3.75mm carbon steel (Q235)
Top Tank Opening	800mm * 1000mm
Tank Cover	4mm aluminum alloy checker plate, manually operable
Walkway	3mm aluminum alloy perforated walkway
Top Protection Device	Aluminum alloy top protection device
Mudguards & Side Guards	Q235 carbon steel
Trailer Frame Material	6mm-thick HJ700 high-strength steel
Longitudinal Beam Web	8mm-thick Q345 high-strength steel
Axle Specification	10-ton axle, 28-ton support legs
Brake System	Drum brakes, equipped with Kemi ABS and manual adjustment arms
Tire Specification	12R22.5
Spring Leaf Quantity & Specification	-/10/10
Fifth Wheel Coupling	Optional 50# or 90#
Power Unit	External hydraulic power unit
Upper-Mounted Unloading System	Eaton hydraulic motor to drive the auger for unloading
