KMH-1900AF Electric Hinge Sweeper


Product Specifications:
  • Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd
  • Product Name: KMH-1900AF Electric Hinge Sweeper
  • Keywords: Road Sweeper
  • Attributes: With After-Sale Service, One Year Warranty, Semi-Trailer

Availability:
Quantity:
  • KANGMU

KMH-1900AF Electric Hinge Sweeper


NAME SPECIFICATIONS
1 Garbage Tank Volume 650L
2 Vehicle Dimension 3600X1600X2200 MM
3 Driving Motor 5KW
4 Disk Brush Motor 160 Ml/R
5 Fan Motor 5.5KW
6 Hydraulic Unit Motor 4KW
7 Air Conditioning 1000W
8 Water Pump Motor 1.2KW
9 Curb Weight 1600KG
10 Turning Radius <2500MM
11 Working Speed 0-10KM/H
12 Continuous Operation Time 4-6 Hours
13 Gradeability 20%
14 Sweep Width 1400-1900MM
15 Highest Working Ability 95M2/H
16 Maximum Water Tank Volume 200L
17 Battery Capacity 36Kw.H
18 Lithium Iron Phosphate Battery 72V/500AH
19 Vehicle Charger 72V

Product Performance:

The pure electric articulated road sweeper is a specialized articulated chassis sweeper with a sweeping and suction function. It is a small-sized sweeper that outperforms similar products in terms of technical performance. It features an attractive appearance and agile operation. It is powered by a 72V/450Ah high-capacity lithium battery pack to drive all its functions. The two sweeping brushes are located on either side in front of the driver's cab, and the suction port is positioned directly below the cab in the center. This layout offers a clear view for cleaning operations and makes the machine easy to operate.

图片 1

左后

驾驶室正后右后正前右45正右
