KMH5180GQWL6
KANGMU
Dongfeng LZM 15Cbm(Without Auxiliary Engine) Combi Suction And Jetting Truck
NAME | SPECIFICATIONS | |
1 | Vehicle Model | KMH5180GQWL6 |
2 | Wheelbase | 4700MM |
3 | Engine Model | YCS06200-60,YCS06245-60A |
4 | Engine Power | 147KW/180KW |
5 | Vehicle Dimensions(L*W*H) | 8750,8850 × 2550 × 3500,3550,3600,3650MM |
6 | Curb Weight | 12575KG |
7 | Total Quality | 18000KG |
8 | Tank Volume | 15CBM |
9 | Fuel Type | Diesel oil |
10 | Emission Standard | National VI |
Upper Body Configuration:
The appearance dimensions are made according to the announcement. It is an integrated tank with a capacity of about 15 cubic meters and a body size of 6mm. It is made of high-quality carbon steel. Cleaning section: 250L/min high-pressure pump, inlet with filter screen, 100m 22 # high-pressure pipe, 1 9.5kg emperor nozzle, 1 1m straight nozzle, and the reel is installed on the rear head. Suction part: 2BE-204 water circulation pump, 8-meter suction pipe. Details: The tank can be lifted, the back cover is hydraulically opened, manually locked, water and sewage are interconnected, there is a 100 ball valve and a 150 ball valve on the rear head, arrow lights, work lighting, with automatic discharge, and a toolbox.
Product Function:
The strong pressure generated by high-pressure water flow breaks open the blocked pipeline. The main components are the tank body, high-pressure pump, hydraulic system, etc. High pressure cleaning vehicles are mainly used to clean sediments and dredge dead corners of urban sewers and pipelines. They can also be used to clean industrial drainage pipelines, walls, etc., and to clean roads and square floors.
Dongfeng LZM 15Cbm(Without Auxiliary Engine) Combi Suction And Jetting Truck
NAME | SPECIFICATIONS | |
1 | Vehicle Model | KMH5180GQWL6 |
2 | Wheelbase | 4700MM |
3 | Engine Model | YCS06200-60,YCS06245-60A |
4 | Engine Power | 147KW/180KW |
5 | Vehicle Dimensions(L*W*H) | 8750,8850 × 2550 × 3500,3550,3600,3650MM |
6 | Curb Weight | 12575KG |
7 | Total Quality | 18000KG |
8 | Tank Volume | 15CBM |
9 | Fuel Type | Diesel oil |
10 | Emission Standard | National VI |
Upper Body Configuration:
The appearance dimensions are made according to the announcement. It is an integrated tank with a capacity of about 15 cubic meters and a body size of 6mm. It is made of high-quality carbon steel. Cleaning section: 250L/min high-pressure pump, inlet with filter screen, 100m 22 # high-pressure pipe, 1 9.5kg emperor nozzle, 1 1m straight nozzle, and the reel is installed on the rear head. Suction part: 2BE-204 water circulation pump, 8-meter suction pipe. Details: The tank can be lifted, the back cover is hydraulically opened, manually locked, water and sewage are interconnected, there is a 100 ball valve and a 150 ball valve on the rear head, arrow lights, work lighting, with automatic discharge, and a toolbox.
Product Function:
The strong pressure generated by high-pressure water flow breaks open the blocked pipeline. The main components are the tank body, high-pressure pump, hydraulic system, etc. High pressure cleaning vehicles are mainly used to clean sediments and dredge dead corners of urban sewers and pipelines. They can also be used to clean industrial drainage pipelines, walls, etc., and to clean roads and square floors.
