Dongfeng Dolika 10Cbm Sewage Suction Truck

Product Specifications:
  • Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd.
  • Product Name: Dongfeng Dolika 10Cbm Sewage Suction Truck
  • Keywords:Sewage Suction Truck
  • Attributes: With After-Sale Service, One Year Warranty, Truck
Availability:
Quantity:
  • KMH5140GXWE6

  • KANGMU

Dongfeng Dolika 10Cbm Sewage Suction Truck



NAME SPECIFICATIONS
1 Vehicle Model KMH5140GXWE6
2 Wheelbase 3800MM
3 Engine Model YCY30165-60
4 Engine Power 121KW
5 Vehicle Dimensions(L*W*H) 6930,7067×2260,2400×3150,3250,3350,2950,3000MM
6 Curb Weight 7385KG
7 Total Quality 14060KG
8 Hydraulic System Pressure 18MP
9 Tank Volume 10CBM
10 Tank Material carbon steel (6MM)
11 Tank Dimension 4200×1700MM
12 Fuel Type Diesel
13 Emission Standard National VI


Upper Body Configuration:

The appearance and dimensions shall be manufactured in accordance with the announcement. It is equipped with a dished head. The rear door of the tank body is hydraulically opened and mechanically locked. The tank body is of lifting and self-unloading type. There is a sewage viewing pipe on the upper part of the right side of the tank body, and a 100 ball valve below the rear head. It is equipped with a 10-ton vacuum pump/SK-9 water circulation pump, a water-oil separator, an anti-overflow valve. The side lights are electrically powered. One 8-meter-long sewage suction pipe is provided, and the rest are standard configurations.

174322987897317432300246081743230116777174323146441517432316673751743231671918
