KMH5070GXEE6
KANGMU
Dongfeng Dolika 5CBM Cesspit Emptier And Suction Truck
NAME | SPECIFICATIONS | |
1 | Vehicle Model | KMH5070GXEE6 |
2 | Wheelbase | 3308MM |
3 | Engine Model | D20TC IF,Q23-136E60,YCY24140-60,Q25-152E60 |
4 | Engine Power | 93KW, 100KW, 103KW, 112KW |
5 | Vehicle Dimension | 5963,5948×2000×2800MM |
6 | Curb Weight | 3775KG, 3910KG |
7 | Total Weight | 7360KG |
8 | Rated Loading Capacity | 3455KG, 3320KG |
9 | Tank Volume | 5 CBM |
10 | Tank Material | 6MM Carbon Steel |
11 | Tank Dimension | 3500×1700×1100MM |
12 | Emission Standard | National VI |
13 | Fuel Type | Diesel |
Product Performance and Features:
The entire vehicle's tank body and metal accessories are sprayed with high - molecular anti - corrosion primer and metal topcoat. The paint has strong adhesion, excellent corrosion resistance, a uniform film, and the color is bright and long - lasting. This improves the aesthetic appearance, enables the vehicle to withstand adverse environments such as humidity, dust, and salt spray, and ensures that problems like cracking, peeling, and fading will not occur during long - term use. It not only enhances the product's aesthetic appeal but also effectively prevents rusting.
The fecal suction vehicle is used to suck feces, sewage, sludge slurry, and liquids mixed with small suspended debris. It can also be used for emergency handling of sudden environmental pollution accidents. By making full use of vacuum technology, the dual anti - overflow pump device can better prevent tank overflow and extend the service life of the vacuum pump. The overall vehicle is designed with a reasonable structure, excellent performance, and is flexible and easy to operate.
The tank body is installed on the vehicle frame in a rigid connection method, and a buffer pad is set in the middle of the two, which can reduce the damage to the tank body caused by the vehicle's vibration. Anti - sloshing plates are installed inside the tank body to reduce the damage to the tank body and its connection parts with the vehicle frame caused by the intense sloshing impact of the liquid during vehicle driving.
