Sinotruk Howo 32Cbm Combi Suction And Jetting Truck

Product Specifications:
  • Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd.
  • Product Name: Sinotruk Howo 32Cbm Combi Suction And Jetting Truck
  • Keywords:Sewage Suction Truck
  • Attributes: With After-Sale Service, One Year Warranty, Truck
Availability:
Quantity:
  • KMH5310GQWZ6

  • KANGMU

Sinotruk Howo 32Cbm Combi Suction And Jetting Truck


NAME SPECIFICATIONS
1 Vehicle Model KMH5310GQWZ6
2 Wheelbase 1950+4625+1350MM
3 Engine Model MAN430
4 Engine Power 316KW
5 Vehicle Dimensions(L*W*H) 12060,11990  ×  2550  ×  3990 ,3950,3900MM
6 Curb Weight 20485KG
7 Total Quality 31000KG
8 Tank Volume 32CBM
9 Fuel Type Diesel oil
10 Emission Standard National VI


Upper Body Configuration:

The appearance dimensions are made according to the announcement. It is an integrated tank with a capacity of about 32 cubic meters and a body size of 8mm. It is made of high-quality carbon steel. Cleaning part: 330L/min high-pressure pump, inlet with filter screen, 100m 22 # high-pressure pipe, 1 9.5kg emperor nozzle, 1 1m straight nozzle, and the reel is installed on the rear head. Suction part: 420 horsepower auxiliary engine+2BE-258 water ring pump, 8-meter suction pipe. Details: The tank can be lifted, the back cover does not open, the tail is equipped with a 600 quick opening with manual locking, water and sewage are interconnected, the rear head has three 100 ball valves, one 150 ball valve, arrow lights, work lighting, with automatic discharge, and a toolbox.


Product Function:

The strong pressure generated by high-pressure water flow breaks open the blocked pipeline. The main components are the tank body, high-pressure pump, hydraulic system, etc. High pressure cleaning vehicles are mainly used to clean sediments and dredge dead corners of urban sewers and pipelines. They can also be used to clean industrial drainage pipelines, walls, etc., and to clean roads and square floors.


17346638459461734663873120173466391592017346639366991734664031732173466412326717346641676331734664207370



Hubei Kangmu Special Vehicle Equipment Co., Ltd. is a professional company that focus on automobile technology research and development, truck manufacturing, spare parts production and sales. Founded in March 2016, it covers an area of 120 acres and has more than 300 employees. We are the professional manufacturer of livestock and poultry transport trucks and trailers, bulk feed transport trucks and trailers, refrigerated truck, medical waste disinfection truck, garbage truck, fuel tank truck, sewage suction truck, water tank truck etc., with quality GB/T19001-2016/ISO9001: 2015 standard, and also complies with GB/T24001/2016/ISO14001: 2015 environmental standard. We fully support customization with your special requirements.


The company′s business philosophy of "quality is the life, service is the soul and integrity is the foundation of an enterprise" help us becoming the stable supplier of some famous and large group companies such as Wen′s, New Hope Group, Muyuan, Zhengbang, DaBeiNong, COFCO, etc. Our advanced technology, excellent quality and service make our products present all over the world, especially popular in Southeast Asia, the Middle East and Africa.


Welcome to visit our factory. We hope to cooperate with the friends from all over the world and make mutual benefits!
