Dongfeng Tuyi 2.6cbm Sprinkler Truck Water Bowser Truck
name | specifications | |
1 | Vehicle Model | KMH5040GSSEQ6 sprinkler truck |
2 | Engine Model | Q23-95E60 |
3 | Engine Horsepower/Power | Quanchai 95HP/70KW |
4 | Engine Displacement | 2300ML |
5 | Transmission | Wanliyang 5 gear |
6 | Tire Specifications | 185 vacuum tire |
7 | Wheelbase | 2800 |
8 | Total Quality | 4495KG |
9 | Curb Weight | 2390KG |
10 | Rated Load Capacity | 1975KG |
11 | Vehicle Dimensions(L*W*H) | 5.75*1.85*2.1 |
12 | Tank Volume | 2.6CBM |
13 | Fuel Type | diesel |
14 | Emission Standard | National VI |
15 | Pump Model | 40/50 |
16 | Tank Material | Q235 carbon steel |
Chassis configuration:
The engine has 95hp, a 5-speed Wanliyang engine, a wheelbase of 2800mm,185 vacuum tires, rear dual wheels, front and rear axles of 1.5/3, power steering, front disc braking, central locking, electric glass, cruise control, ABS, air conditioning, multifunctional steering wheel, and oil brake.
Upper body configuration:
1. The tank body is approximately 2.6 cubic meters.
2. Punching platform (with enhanced load-bearing capacity), and the rear cover of the barrel is a customized bolt buckle.
3. Rear hedge, rear spray, side spray, and greening anti-aircraft gun switch ball valves all use engineering specific 50 large diameter copper ball valves.
4. The new bearing type water cannon is more durable.
5. 40-50 type water pump.
6. Anti corrosion flange gasket.
7. Aluminum is not easy to explode after sprinkling.
8. Automatic welding of tank body (Lincoln welding machine and power supply from the United States), automatic welding of panel assembly, welding of head and circumferential seams, and aesthetically pleasing welds without porosity.
9. The side guard and rear bumper are all bolted together for easy disassembly and maintenance.
10. Plastic mudguards, replacing iron mudguards, are more lightweight and connected with bolts for easy disassembly.
11. The connection between the front and rear main pipes is a 6-hole circular flange, which is not easy to pad.
