Dongfeng Huashen 30CBM Sprinkler Truck

Product Specifications:
  • Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd.
  • Product Name: Dongfeng Huashen 30CBM Sprinkler Truck
  • Keywords: Water Sprinkler Truck
  • Attributes: With After-Sale Service, One Year Warranty, Truck
Availability:
Quantity:
  • KMH5310GPSEQ6A

  • KANGMU

Dongfeng Huashen 30CBM Sprinkler Truck


NAME SPECIFICATIONS
1 Vehicle Model KMH5310GPSEQ6A sprinkler truck
2 Engine Model YCS06270-60
3 Engine Horsepower/Power Yuchai 270 horsepower/199kw
4 Engine Displacement 6234ML
5 Transmission Case Fast 8 gear
6 Tire Specifications 11.00 steel wire tire
7 Wheelbase 1850+3200+1350mm
8 Total Quality 31000KG
9 Curb Weight 13320KG
10 Rated Load Capacity 17485,17550KG
11 Vehicle Dimensions(L*W*H) 11150mm,11310,11650,11810×2 550×3400
12 Tank Volume 7900×2530×1730
13 Seats
2
14 Fuel Type Diesel oil
15 Emission Standard National VI B
16 Pump Model 60/90
17 Tank Material Q235 carbon steel



Chassis configuration:

Dongfeng Huashen T5 cab, Yuchai 270 engine, wheelbase of 1850+3200+1350mm, Fast 10 speed gearbox, 11.00 wire tires, air conditioning, airbag seats, central control, multifunctional steering wheel, driving recorder.


Upper body configuration:

1. The tank body is approximately 30 cubic meters.

2. The side lights are electrified, and two red width lights are standard above the tail of the tank.

3. The standard front spray is a duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

4. Punching platform (with enhanced load-bearing capacity), and the rear cover of the barrel is a customized bolt buckle.

5. The front spray, back flush, back spray, and side spray, as well as the green anti-aircraft gun switch ball valve, all use 50 large diameter stainless steel ball valves.

6. The new bearing type water cannon is more durable.

7. 60-90 type water pump.

8. Anti-corruption flange gasket.

9. Aluminum is not easy to explode after sprinkling.

10. Automatic welding of tank body (Lincoln welding machine and power supply from the United States), automatic welding of panel assembly, welding of head ring seam, no porosity, and beautiful weld seam.

11. The side guard and rear bumper are all bolted together for easy disassembly and maintenance.

12. Plastic mudguards, replacing iron mudguards, are more lightweight and connected with bolts for easy disassembly.

13. The connection between the front and rear main pipes is a 6-hole circular flange, which is not easy to pad.








图片 4图片 5图片 6图片 8图片 7图片 9图片 10图片 11
