Dongfeng Furuika 9.3CBM Sprinkler Truck Water Bowser Truck Vacuum Sprinkler Truck

Product Specifications:
  • Company: Hubei Kangmu Special Vehicle Equipment Co., Ltd.
  • Product Name: Dongfeng Furuika 9.3CBM Sprinkler Truck Water Bowser Truck Vacuum Sprinkler Truck
  • Keywords: Water Sprinkler Truck
  • Attributes: With After-Sale Service, One Year Warranty, Truck
Availability:
Quantity:

Dongfeng Furuika 9.3CBM Sprinkler Truck Water Bowser Truck Vacuum Sprinkler Truck



name specifications
1 Vehicle Model KMH5120GSSEQ6 sprinkler truck
2 Engine Model D30TCIF1
3 Engine Horsepower/Power Yunnei 170HP/125KW
4 Engine Displacement 2977ML
5 Transmission FAST 8 gear
6 Tire Specifications 8.25 Steel Wire Tire
7 Wheelbase 3800
8 Total Quality 11995KG
9 Curb Weight 4600KG
10 Rated Load Capacity 7200KG
11 Vehicle Dimensions(L*W*H) 7.1*2.25*2.8
12 Tank Volume 9.3CBM
13 Fuel Type diesel oil
14 Emission Standard National VI
15 Pump Model 40/50
16 Tank Material Q235 carbon steel




Chassis configuration:

The engine has 170 horsepower ( 4 cylinder), a Fasttech 8-speed gearbox, 8.25 steel tires, a wheelbase of 3800, a gas brake, ABS, air conditioning, electric lift glass, and a central locking system.


Upper body configuration:

1. The tank volume is approximately 9.3 cubic meters.

2. The side lights are electrified, and two red width lights are standard above the tail of the tank.

3. The standard front spray is a duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

4. Punching platform (with enhanced load-bearing capacity), and the rear cover of the barrel is a customized bolt buckle.

5. The front spray, back flush, back spray, and side spray, as well as the green anti-aircraft gun switch ball valve, all use engineering specific 50 large diameter copper ball valves.

6. The new bearing type water cannon is more durable.

7. 40-50 type water pump.

8. Anti corrosion flange gasket.

9. Aluminum is not easy to explode after sprinkling.

10. Automatic welding of tank body (Lincoln welding machine and power supply from the United States), automatic welding of panel assembly, welding of head ring seam, no porosity, and beautiful weld seam.

11. The side guard and rear bumper are all bolted together for easy disassembly and maintenance.

12. Plastic mudguards, replacing iron mudguards, are more lightweight and connected with bolts for easy disassembly.

13. The connection between the front and rear main pipes is a 6-hole circular flange, which is not easy to flush with the gasket

图片 8图片 2图片 3图片 4图片 5图片 6
